TR-73-NL-M
Wheels with standard duty brackets and medium duty brackets

Sigma Elastic rubber tread, polyamide 6 centre



loading

Technical specifications

Scroll horizontally
Wheel description

Wheel description

Non-marking blu elastic rubber wheels; hardness 70 Shore A. Polyamide 6 centre.

Bracket description

Bracket description

Swivel bracket with bolt hole type NL. The plate,ball race ring and fork are of pressed steel zinc plated finish; swivel actions: double ball greased race. Galvanised steel solid stem. The king pin is integral with top plate and duly rivetted.

Environments of use

Environments of use

Designed for industrial environments, even in presence of medium-harsh chemical agents. Not suitable in presence of organic, aromatic solvents, chlorinated substances and hydrocarbons.

giallo
Weak acids
rosso
Strong acids
verde
Water
verde
Alcohol
giallo
Weak bases
giallo
Strong bases
giallo
Hydrocarbons
rosso
Solvents
Floors

Floors

Suitable for all types of floors, even outdoors. They facilitate the overcoming of obstacles. They do not damage or mark floors.

asfalto
Asphalt
cemento-resine
Cement Resin
grigliato
Expanded Metal
con-ostacoli
With Obstacles
piastrelle
Tile
sterrato
Not Paved
con-trucioli
With Chips
Force required to push or tow a wheel

Force required to push or tow a wheel

For each load and diameter, the table indicates the force (in daN) needed to push or tow a single wheel at the constant speed of 4 km/h on smooth flooring. For manual handling of a 4-wheeled trolley we recommend diameters that have values 5 daN, for frequent handling we recommend diameters with values 3 daN.

DiameterWidth50100150200300400
1000258
12501,8357
160012358,5
1800<11235,5
2000<1<111,73,56,5
Models all rights reserved in accordance with the law. Always mention the source when reproducing our drawings and photos.
